Details
High rigidity because of the box structure to keep the slider.
65, 100 and 200 are available for the mount width.
Available angle is 0° to 70°, in increments of 5°.Automatic alignment mechanism of the V-shaped Guide.
JIS Cam Series
High rigidity because of the box structure to keep the slider.
65, 100 and 200 are available for the mount width.
Available angle is 0° to 70°, in increments of 5°.Automatic alignment mechanism of the V-shaped Guide.
